HYDAC oil cooler Heat Exchangers and Cooling Systems

–a Cool Solution for Every Application
Hydraulic and lubrication systems play a major role in almost all stationary and
mobile machines. The fluids used transmit power, provide lubrication,
channel away heat and protect from corrosion.
The quality of the fluid is the fingerprint of the whole system. The temperature
control and purity of the fluid, for example, are crucial factors for the state of
the entire control equipment in mobile-hydraulic applications.
In all hydraulic systems, energy is converted and transported.
This involves some energy being lost, in the form of heat. The task of the cooling
systems is to dissipate the heat.
Efficient cooling systems can help to lengthen the service life of the operating
fluids and filters used and reduce life cycle costs.
HYDAC Cooling’s product range includes coolers, heat exchangers and
cooling systems for almost all industries and applications.
We can cool not only hydraulic systems but also electric drives and motors,
generators, inverters and transformers.
Our cooling systems enable gearboxes to be cooled and lubricated and mobile
working equipment and vehicles to keep going for longer.
Whether your cooling involves air or water, return flow or bypass flow,
standard or customized solutions – we are always happy to help.

Air Coolers for Stationary Industrial Applications

AC-LN 1-7
Standard air cooler with axial fan
ACA-LN 2-7
Air cooler with pump
ACAF-LN 2-7
Air cooler with pump and filter

AC-LN 8-14
Low-noise air cooler with axial fan
ACA-LN 8-11
Air cooler with pump
ACAF-LN 8-11
Air cooler with pump and filter

AC-LN MI 8-14
Low-noise air cooler with axial fan
With integrated frequency inverter
Continuously adjustable speed-control in accordance
with the fluid temperature in the cooling element
Regulated cooling capacity

OSCA/OSCAF 0-3
Optimized air cooler with radial fan
OSCA: air cooler with pump
OSCAF: air cooler with pump and filter

OK-ELC 0-7 Oil / air cooler  Compact motor-fan unit Air Coolers for Mobile Applications
OK-ELD 0-6 Air cooler with DC motor (12 V and 24 V) Compact and performance-optimized
Cooling of oils or coolants

OK-ELH 2-7 / AC-LNH 8-14 Air cooler with hydraulic motor (6.3 – 22 cm³/U)
Very low noise level
Flexible use
Cooling of oils or coolants

CMS – Cooling Mobile System,Combination cooler for customized solutions
Compact design
Special cooling air fins or coating methods
for use in dusty or aggressive environments
Combination of several cooling circuits
(coolant, charge air, hydraulic)
