Combined Bar Plate Heat Exchanger

Combined Bar Plate Heat Exchanger

Combined bar plate heat exchanger is ORCAER focus for many years of continuous design research and development of important projects,
ORCAER can be in accordance with the requirementsof any parameters, customized best suited to your heat transfer solution,Such as heat source, heat transfer, temperature, heat transfer medium temperature, space size, inlet and outlet temperature, parameters of any engine
Any heat source need to change the place we can solve it

Optional different fin type
Optional different aluminium thickness and models
Customize different sizes of core body
Optional different type tank (Casting and manual welding)
Optional in different wind cover type (Seal plate or circular steel wire coil)
Optional different drive mode (AC/DC/ Hydraulic motor/Pneumatic fan)
Optional different types of blades
(The nylon material, iron material, aluminum material)
Optional to increase the heat transfer medium filtering system
Optional different temperature sensors and electrical switch
(Water temperature sensor, oil temperature sensor) (Cable and wireless control switch)
Can combination of water and oil heat exchanger,gas water heat exchanger, gas oil heat exchanger and other customized different medium heat exchanger in combination

Special Advantage：

Composite heat exchanger assembly by a variety of monomers,
One-piece attain the goal of a variety of heat transfer medium
The structure is compact, modular design, save a space
Work alone, separate maintenance convenient maintenance
Optional steel and aluminum frame according to the environment
Optional AC/DC fan motor, hydraulic motor, pneumatic fan
Optional combination gas oil, gas water combination, combination of water and oil
More than 6 kinds cooler of combinations
